B3 Water Pump - Mechanical Seal
B3 Water Pump - Mechanical Seal
The B3 water pump has been a staple of the industry for many years. The B3 water pump originated from the USA and is great for direct drive applications where the pump is driven via a drive shaft connected to the trucks PTO.
Direct drive is not what we would recommend for new builds. We recommend water pumps be driven via a variable displacement hydraulic system.
However, if you're on a tight budget, then this pump provides excellent bang for the buck.
Traditionally B3 water pumps were sealed with a rope packing seal with is not ideal as they continually leak. Our B3 pumps feature a mechanical seal that eliminates the constant dripping that traditional plages this pump.
Are you looking for a hydraulic pump? Check out our XHD Pump—a modern take on this old classic.
Specifications
| Inlet | 100mm (4") Roll Groove |
| Outlet | 80MM (3") Roll Groove |
| Max Speed | 2500 RPM |
| Shaft | 1-1/8 1/4 Keyway |
| Shaft Material | High tensile 1040 |
| Impeller Material | Cast Iron |
Performance
| Max Power | 40HP 30KW |
| Max Flow | 43PSI @ 3785LPM 30KW |
| Max Pressure | 80PSI @ 1000 LPM 15KW |
| Max Efficiency | 70PSI @ 2450LPM 23KW |
Express Post - AUD$27.27
| SKU | WP-B310080MS-CW |
| Brand | T-Rex |
| Unit Of Measure | ea |
B3 Water Pump - Mechanical Seal
The B3 water pump has been a staple of the industry for many years. The B3 water pump originated from the USA and is great for direct drive applications where the pump is driven via a drive shaft connected to the trucks PTO.
Direct drive is not what we would recommend for new builds. We recommend water pumps be driven via a variable displacement hydraulic system.
However, if you're on a tight budget, then this pump provides excellent bang for the buck.
Traditionally B3 water pumps were sealed with a rope packing seal with is not ideal as they continually leak. Our B3 pumps feature a mechanical seal that eliminates the constant dripping that traditional plages this pump.
Are you looking for a hydraulic pump? Check out our XHD Pump—a modern take on this old classic.
Specifications
| Inlet | 100mm (4") Roll Groove |
| Outlet | 80MM (3") Roll Groove |
| Max Speed | 2500 RPM |
| Shaft | 1-1/8 1/4 Keyway |
| Shaft Material | High tensile 1040 |
| Impeller Material | Cast Iron |
Performance
| Max Power | 40HP 30KW |
| Max Flow | 43PSI @ 3785LPM 30KW |
| Max Pressure | 80PSI @ 1000 LPM 15KW |
| Max Efficiency | 70PSI @ 2450LPM 23KW |
| SKU | WP-B310080MS |
| Brand | T-Rex |
| Unit Of Measure | ea |
Express Post - AUD$27.27
